PulseVi 3D Solid-State LIDAR Security System

Home > Products > PulseVi 3D Solid-State LIDAR Security System

PulseVi 3D Solid-State LIDAR Sensor Security System

Perimeter Security with 3D Solid State Scanning LiDAR

  1. All-In-One LiDAR: Operates independently with no computer or server required.
  2. Dual Output: Provides both point cloud data and a camera-like video feed.
  3. Ultra-Fast Scanning: Captures at 30 frames per second (FPS).
  4. Energy Efficient: Low power consumption of only 10W.
  5. Quick and Easy Deployment: Simple setup and configuration.
  6. Advanced Detection: AI-powered, signature-based detection for classification-based alerts.
  7. Flexible Installation: Operates effectively in vertical or horizontal positions.
  8. Reliable Design: No moving parts, ensuring durability and low maintenance.
  9. Remote Control and Monitoring: IP-based access with software-configurable zones.
  10. Weather-Resistant: IP65-rated enclosure for robust outdoor use.
  11. PoE Option Available: Power over Ethernet version for streamlined power and data integration.
  12. Works in extreme temperatures (from -40°C to +85°C) and in all weather conditions
PulseVi 3D Scanning Solid State LiDAR

What is a 3D solid state LIDAR and Why Do You Need One for perimeter security?

A 3D solid-state LiDAR (Light Detection and Ranging) is an advanced sensor technology used to create detailed, three-dimensional maps of an environment by emitting laser beams and measuring their reflection. Unlike traditional rotating LiDAR systems, solid-state LiDAR has no moving parts, making it more durable, reliable, and cost-effective. For perimeter security, a 3D solid-state LiDAR offers unmatched precision in detecting, tracking, and identifying intruders across large areas, even in harsh weather conditions or low light environments. Its ability to provide real-time, high-resolution data enhances threat detection accuracy, reducing false alarms and improving overall security efficiency.



  1. A 3D solid-state LiDAR provides an “early warning” of perimeter breaches by detecting motion or presence in real time, allowing proactive security measures.
  2. LiDAR technology enables you to react instantly by integrating with sirens, lights, or security protocols to deter intruders as soon as they approach your perimeter.
  3. Transform your existing perimeter into a cutting-edge security barrier without additional infrastructure costs by leveraging 3D LiDAR’s precise detection capabilities.
  4. LiDAR is an economical way to enhance perimeter security by integrating it seamlessly with existing security systems, acting as an intelligent sensor within your network.
  5. Maximise loss prevention and ensure a strong return on investment by receiving real-time alerts when intruders are approaching, rather than waiting until they are already inside.

HERE ARE FOUR REASONS WHY MICROWAVE SENSORS AND INFRARED BARRIERS ARE NOT ENOUGH:

  • Lack of Target Classification: Microwave and infrared sensors provide basic yes/no detection, unable to distinguish between humans, animals, or debris. In contrast, LiDAR can classify targets by size, direction, and speed, reducing false alarms and improving detection accuracy.
  • High Installation Costs: Microwave sensors often require civil work, such as trenching and installing poles, which dramatically increases costs. LiDAR operates on low power and can be solar-powered, eliminating the need for costly infrastructure.
  • Environmental Limitations: LiDAR is unaffected by pooling water and uneven terrain, allowing flexible placement at various angles and heights. Microwave sensors and infrared barriers need flat ground and precise sensor alignment, making them less adaptable.
  • Rigid Detection Zones: Microwave and infrared systems require clear, direct line-of-sight between sensors, leaving potential blind spots. LiDAR offers adjustable 3D detection zones, ensuring full perimeter coverage without gaps.

HOW DOES LIDAR DETECT HUMANS AND VEHICLES, BUT NOT WEATHER OR ANIMALS?

LiDAR technology offers advanced intrusion detection with multiple layers of false alarm filtration:

  1. Target Classification: LiDAR can distinguish between humans and vehicles by analyzing the size, speed, and direction of a moving object, filtering out smaller objects like animals and debris that don’t match the profile of an intruder.
  2. Environmental Filtering: LiDAR is immune to weather conditions like rain, wind, and fog, as it only detects solid objects, not atmospheric disturbances. This ensures accurate detection, regardless of weather.
  3. Customizable 3D Detection Zones: With adjustable 3D zones, LiDAR can fine-tune its detection area to focus on relevant threats, such as people or vehicles, while ignoring non-threatening environmental factors.

Get Better Perimeter Protection for
Sites Such as those:

  • Critical Infrastructure: Precise perimeter monitoring (power plants, water facilities).
  • Transportation: Airport, rail, and port security (runways, tracks).
  • Border Security: National and coastal borders (illegal crossings).
  • Industrial Facilities: Warehouses and manufacturing (theft detection).
  • Data Centers: Perimeter and interior protection (server rooms).
  • Prisons: Perimeter security (virtual fence, showers).
  • Military Bases: Base and weapon storage (intrusion detection).
  • Smart Cities: Public spaces and urban areas (parks, stadiums).
  • Healthcare: Hospitals and pharmaceutical facilities (areas with privacy concerns).
  • Residential: Gated communities and private estates (high-security with privacy).
  • Event Security: Concerts and public gatherings (crowd management and temporary security for soft spots).

3D LiDAR Security Solution Intrusion Detection

3D LiDAR Security Solution in Busy Areas
